The MINI II series is an evolved version of G5 MINI. The evolved version is not only to keep original advantages, but to provides more competitiveness in both performance and cost. In addition, MINI II platform can be easily converted to be customized as always.
Low copper Al alloy with high corrosion resistance powder coating.
Tool-less operating latch, easy for power compartment opening and closing
Suitable for side entry and post top without additional parts.
Hidden heat sink avoids contaminants accumulated.
Compact and light weight, saving logistic cost
Excellent efficacy enables significant energy cost saving
| Operation Voltage Range | 85 – 305Vac |
| Input Frequency | 50/60 Hz |
| Power Factor (note 1) | ≧0.95 @230Vac |
| Total Harmonic Distortion (note 2) | ≦10 @230Vac |
| Surge Protection | 10KV |
| Typical Color Temperature (note 3) | 4000K |
| Net Weight | 4.5 kg |
| Ingress Protection Rating | IP66 |
| Operating Temperature | -40℃ – 50℃ |
Note:
1.For those models that power consumption is below 50W, the power factor is higher than 0.9
2.For those models that power consumption is below 50W, the THD is less than 15%
3.Other color temperatures are available upon request
| Model Number | Power Consumption(Watt) | Luminous Flux(lm) |
| TSL-1507-09 | 70 | 9,400 |
| TSL-1006-09 | 55 | 7,750 |
| TSL-1005-09 | 45 | 6,700 |
| TSL-0704-09 | 35 | 4,400 |
| TSL-0703-09 | 28 | 3,700 |
| TSL-0502-09 | 23 | 3,100 |
Edge X manages street lights as an asset. Lighting can be tuned based on the traffic and pedestrian flow to maximize energy saving without compromising safety.
Edge X has an intuitive user interface. It allows the user to view their asset on the map, manage and perform tasks remotely.
Edge X can manage Digital Signage which can provide information for pedestrian and provide targeted marketing based on pedestrian focused contextual analytics.
Edge X allow public to report failure of devices and enables authorities to record, track and analyze events to improve the quality of service.
Edge X can monitor energy consumption of devices. This information can help user to manage and achieve targeted energy saving.
Edge X can manage a portfolio of devices in an increasingly complex city setting. It is an easy to use single entry portal to manage all devices like poles, sensors, cameras and so on.
